RIDGEBACK Arcus 1 Open 2024
Model Year | 2024 |
---|---|
Options | Small 2-5 Days Medium 2-5 Days |
Product | The Ridgeback Arcus 1 is an affordable and rugged E-bike, built for a comfortable ride on road and gravel. The Sportdrive M155 motor offers 250 watts of pedal assist and up to 40nm of torque, all the way up to 25km/h making climbs disappear and maintaining momentum on flatter roads. A suspension fork with 63mm of travel is paired with wide 45mm tyres to provide comfort over rough roads, and the capability to head off the beaten track on towpaths and gravel tracks. Hydraulic disc brakes keep everything under control in this great value package. Weight - 29.2kg |
Frame | SportDrive 6061 Heat Treated Aluminium |
Fork | ZOOM CH187, 63mm Travel |
Rear Derailleur | Shimano Acera RD-M360 8-Speed |
Shifters | Shimano Acera SL-M310 8-Speed |
Chainset | SportDrive 170Mm, 42t |
Chain | KMC X8E |
Freewheel | Shimano CS-HG31 11-34t |
Stem | Alloy, 65mm, +9Deg |
Handlebars | Alloy 9Deg Backsweep, 31.8mm Barbore, 680mm Width |
Rims | Alloy J19SZ 36h |
Front Hub | KT-TD8F / SportDrive M155 36h |
Rear Hub | KT-TD8F / SportDrive M155 36h |
Spokes | Steel 14g |
Tyres | WTB Riddler 700x45c Reflex |
Saddle | Ridgeback Metro |
Seatpost | Alloy 27.2x350mm |
Pedals | Ridgeback Metro |
Grips | Single Density Lock On |
Extras | Charger - SportDrive 2AH |
Brakes | Shimano BR-MT200 Hydraulic Brakes Rotors - Shimano SM-RT26, 160mm, 6 bolt |
Motor | SportDrive M155, 250w, 40nm |
Battery | SportDrive 313wh |
As with any product, specification is subject to change without prior notification. You are advised to confirm current specification before buying.
