MARIN Rift Zone C XR 29 2023

   Pinterest PinIt
Pricing
£3420.00



Finance* from £81.75 per month

*subject to status, minimum spend applies

Hover mouse for full example.
Model Year 2023
Options S Gloss Grey Carbon Out Of Stock
M Gloss Grey Carbon In Stock (Warehouse)
L Gloss Grey Carbon In Stock (Warehouse)
XL Gloss Grey Carbon In Stock (Warehouse)
Product The Rift Zone is our most speed oriented MultiTrac bike, created for the rider looking for the speed and roll over capabilities of 29" wheels in a trail capable package.
The Rift Zone represents the most modern 29" short travel trail bike possible featuring 125mm of MultiTrac suspension and progressive geometry that takes full advantage of decades of trail riding experience to create best-in-class handling, both in and out of the saddle. The Rift Zone is available with a carbon fiber or aluminum front triangle and is an ideal bike for mixing it up between long trail days in the saddle and fast weeknight group rides.
Frame: All New Unidirectional Carbon Fiber Front Triangle, Series 4 Alloy Rear End, 29" Wheels, 140mm Travel, MultiTrac Suspension Platform, 148x12mm Boost Thru-Axle, 73mm Threaded BB w/ ISCG05 Tabs
Rear Suspension: Rock Shox Super Deluxe Ultimate, 210x55mm, 25xM8 Hardware, Custom Tune
Fork: Rock Shox Lyric Ultimate, 150mm Travel, 29", 110x15mm Maxle Stealth, 44mm Offset
Headset: FSA No 57, Sealed Cartridge Bearings, 1 1/8" x 1 1/2"
Stem: Marin CNC Stem, 35mm Length, 35mm Bar Bore
Handlebar: Marin Trail Bar, 35mm Clamp, 7000 Alloy Bar, 800mm Length, 20mm Rise, 5 Degree Up, 8 Degree Back
Grips: Marin Grizzly Lock-On
Brake Levers: Sram Code Bronze Hydraulic Disc Brakes
Brakes Front: Sram Code Bronze 4-Piston Hydraulic Disc Brakes, HSC 200mm Rotor
Brakes Rear: Sram Code Bronze 4-Piston Hydraulic Disc Brakes, HSC 180mm Rotor
Tires: Maxxis Assegai 29x25, MAXX GRIP, EXO+ Casing, Tubeless Compatible
Rim: Marin Aluminum Double Wall, 29mm Inner, Welded Joint, Disc Specific, Tubeless Compatible
Hub Front: Formula, DC-711, 110x15mm, 6-Bolt Disc, 32h
Hub Rear: Formula, DCL-3482, 148x12, 4 Sealed Bearings, 6-Bolt Disc, XD Driver, 32H
Spokes: 14g Black Stainless Steel
Derailleur Rear: Sram GX EAGLE AXS T-Type
Shift Lever: Sram AXS POD MMX
Chain: Sram GX Eagle T-Type
Cassette: Sram GX 1275 T-Type 10-52T
Crankset: Sram GX Eagle, 32T, 55MM CL, 170MM Length
Bottom Bracket: Sram DUB MTB 73
Pedals: -
Saddle: Marin Speed Concept
Seatpost: TranzX, YSP23JL, 1x Remote, Size S 150mm Travel, Size M and L 170mm Travel, Size XL 200mm Travel, 30.9mm
Extra1: Bolt-On 12mm Thru-Axle, 174mm Length, 1.0 Thread Pitch, 16.5mm, Tapered Head
As with any product, specification is subject to change without prior notification. You are advised to confirm current specification before buying.
